TOPTE is committed to providing highly reliable display solutions for smart devices. To address the challenges of complex industrial environments and long-term continuous operation, the company has introduced LCD display modules featuring high stability, interference resistance, and wide-temperature operation capabilities. These products are widely used in applications such as smart meters, smart home devices, and outdoor equipment.
Product:8″ Smart Charging Station with High-Brightness Waterproof Touchscreen
Resolution：800×600
Overall Dimensions（mm)：147.6（V）×184.4（H）×10.38（T）
VA(mm)：121.5(H) × 162(W)
Key Features:
- Integrated NFC antenna: Supports contactless card payments
- AF anti-fingerprint + AG anti-glare: Keeps the screen clean and clear
- 1000 nits High Brightness: Visible in bright outdoor light; clear charging information
- G+G Multi-touch Waterproof: Operates normally in rain or with wet hands
- 4mm CG Glass | IK09 Impact Resistance: Rugged and durable
Product:5″LTPS HD Touchscreen Display
Resolution： 720×1280
Brightness：500nit
Key Features:
- High refresh rate + fast response: Smooth visuals with no motion blur
- In-Cell touch-display integration + full lamination: Responsive touch, thinner screen
- MIPI Interface: Low power consumption, suitable for portable devices
- Applications: Outdoor live streaming | Drone control | 3D printing | HD PDAs | Handheld terminals | Outdoor energy storage
Product:COG Electricity Meter
Resolution：168 section
Overall Dimensions：74.0*24.0*2.80（mm）
VA：65.0×21.0（mm）
Temperature Range：OPERATING TEMP：-25℃~+80℃，STORAGE TEMP：-30℃~+85℃
Reliability：85℃ 85%RH*1000 hours
Product:Collector
Resolution：160*160dots
Overall Dimensions：72.2*66.55*4.3（mm）
VA：60.0×60.0（mm）
Temperature Range：OPERATING TEMP：-40℃~+70℃，STORAGE TEMP：-30℃~+80℃
Reliability：85℃ 85%RH*500 hours
Product:Optical valve
Structure：LCD+PIN
Overall Dimensions：96.5*38 (MM)
Form：Positive, transmissive
VA：89.5*35(MM) AA：10:30’clock
Product:Temperature Controller
Resolution：320*180 dots
Overall Dimensions：108.8*73.3*4.45 (mm)
VA：98*56 (mm)
Temperature Range：OPERATING TEMP：-10℃~+60℃，，STORAGE TEMP：-20℃~+70℃
Reliability：60℃ 95%RH*500 hours
HMI module list
| Size | Type | Resolution | LCD AA | Interface | （ZIF/BTB） | Brightness | Temperature |
| 3.5″ | TN | 320×240 | 36.72*48.96 | MCU | 24 PIN ZIF | 250cd/m² Typ. | OPERATING: -20°C~70°C STORAGE: -30°C~80°C |
| 4.3″ | TN | 480X272 | 95.04*53.86 | RGB | 40PIN ZIF | 250cd/m² Typ. | OPERATING: -10°C ~ 60°C STORAGE:-20°C~ 70°C |
| 4.3″ | IPS | 800×480 | 95.04×53.86 | RGB | 40PIN ZIF | 350cd/m² Min. | OPERATING: -20°C~ 70°C STORAGE:-30°C~ 80°C |
| 5.0″ | IPS | 800×480 | 108*64.8 | RGB | 40PIN ZIF | 600cd/m² Typ. | OPERATING: -20°C~70°C STORAGE: -30°C~80°C |
| 7″ | TN | 800×480 | 154.08*85.92 | RGB | 50PIN ZIF | 250cd/m² Typ. | OPERATING: -10°C~50°C STORAGE: -20°C~60°C |
| 7″ | IPS | 1024×600 | 154.21*85.92 | MIPI | 36PIN ZIF | 250cd/m² Typ. | OPERATING: -10°C~50°C STORAGE: -20°C~60°C |
| 10.1″ | IPS | 1024×600 | 222.72*125.28 | RGB | 50PIN ZIF | 530cd/m² Typ. | OPERATING: -20°C~50°C STORAGE: -20°C~60°C |
| 15.6” | IPS | 1920×1080 | 344.16*193.59 | eDP | 30PIN BTB | 350cd/m² typ | OPERATING: -10°C~50°C STORAGE: -20°C~60°C |
