TOPTE offers display module solutions with wide temperature operation, moisture resistance, and anti-fog capabilities for smart home appliances.
These displays ensure clear readability of parameters across various environments in products such as refrigerators, air conditioners, and small appliances.Anti-contamination surface treatments resist oil and water stains, while maintaining responsive and stable touch performance—supporting the intelligent upgrade of home appliances and improved user experience.
Description：9″ 1024×600 IPS
Structure ：TFT+CTP
LCDAA：196.61*114.15
Temperature Range：OPERATING TEMP: -20°C~70°C
STORAGE TEMP: -30°C~80°C
Connection Mode：40PIN ZIF
Resolution：41 section
Overall Dimensions：93*38.8*8(mm)
VA：88*29.5(mm)
Temperature Range：OPERATING TEMP：-工作：-30℃~+80℃，STORAGE TEMP：-30℃~+80℃
Reliability：40℃ 90%RH*1000 hours
Product:10.1″Smart Home Control Panel
Resolution： 800×1280
Brightness：500nit
Key Features:
- INCELL Touch-Display Integration: Precise touch response with a feel just like a smartphone
- Laminated Display Technology: Reduces glare and offers a wider viewing angle
- Responsive Touch | Laminated Anti-Glare | Clear visibility indoors
Smart home modle list
Size | Type | Resolution | Temperature | LCD AA | Interface | Connector | Luminance |
2.8“ | TN | 240×320 | OPERATING: -20°C~70°C | 43.2*57.6 | 16 Bit MCU | 36PIN ZIF | 240cd/m²（min） |
2.8 | IPS | 240×320 | OPERATING: -20°C~70°C | 43.2*57.6 | 16 Bit MCU | 36PIN ZIF | 240cd/m²（min） |
8.0 | IPS | 800×1280 | OPERATING: -20°C TO 60°C | 107.64*172.22 | MIPI | 40PIN ZIF | 250cd/㎡ Typ. |
10.1″ | IPS | 1024×600 | STORAGE:-20°C TO 70°C, | 222.72*125.28 | RGB | 50PIN BTB | 300cd/m² TYP |
10.1″ INCELL | IPS | 800X1280 | OPERATING: -20°C TO 60°C | 135.36*216.58 | MIPI | BTB 40PIN/ ZIF 40PIN | 300cd/m² TYP |
