TOPTE provides high-brightness, low-power display solutions optimized for wearable devices.
These modules effectively reduce ambient light reflection, ensuring clear readability even under direct sunlight. With optimized always-on display performance and narrow bezel designs, they balance functionality and aesthetics, enhancing user experience and product competitiveness.
图片宽度:300px, 图片高度:300px
Size：1.22 inches
AA ：∅33.552
Resolution：466*466
Overall Dimensions：41.1*2.13（Excluding FPC&NPC）
Temperature Range：OPERATING TEMP: :-20°C – 70°C；STORAGE TEMP: :-30°C – 80°C
| Size | 1.73″ |
| Resolution | 466×466 |
| Interface | QSPI |
| Temperature | OT: -40°C~85°C ST: -40°C~90°C |
| Brightness | 700cd/m² |
Touch | Oncell |
Wearable module list
Application | Size | TFT TYPE | Color Pixel | Temperature | Luminance (with- without TP) |
Type | Touch | ||||
Wearable | 1.43” oncell | Amoled | 466*466 | OPERATING TEMP: -10 °C~60 °C STORAGE TEMP: -20 °C~70 °C | 600cd/㎡ typ |
1.85” oncell | Amoled | 390*450 | OPERATING TEMP: -10 °C~60 °C STORAGE TEMP: -20 °C~70 °C | 500cd/㎡ typ | |
1.97” oncell | Amoled | 390*450 | OPERATING TEMP: -10 °C~60 °C STORAGE TEMP: -20 °C~70 °C | 600cd/㎡ typ | |
1.73” oncell | Amoled | 466*466 | OPERATING TEMP: -40 °C~85 °C STORAGE TEMP: -40 °C~90°C | 700cd/㎡ typ | |
1.576” oncell | Amoled | 256*402 | OPERATING TEMP: -20 °C~70 °C STORAGE TEMP: -30 °C~80 °C | 600cd/㎡ typ | |
1.75” oncell | Amoled | 390*450 | OPERATING TEMP: -20 °C~70 °C STORAGE TEMP: -30 °C~80°C | 600cd/㎡ typ | |
1.72” oncell | Amoled | 520*212 | OPERATING TEMP: -20 °C~70°C STORAGE TEMP: -30 °C~80°C | 600cd/㎡ typ |
