A wide range of core circuit options are available to meet the needs of different scenarios:
4-wire series: Supports three structural configurations, namely (F+G), (P+F+G), and (P+F+F+G).
5-wire series: Supports two structural configurations, namely (F+G) and (P+F+G).
8-wire series: Supports three structural configurations, namely (F+G), (P+F+G), and (P+F+F+G).
| Number | Size | Model | Product Type | Structure | Dimensions/W*H*D（mm） | LCD AA（mm） | Interface |
| 1 | 2.0″ | QR46286 | Four-wire resistive touch screen | F+G | 47.85*42.37 | 39.10*31.90 | FPC |
| 2 | 2.4″ | HR410243 | Four-wire resistive touch screen | F+G | 58.80*42.12 | 49.86*37.72 | FPC |
| 3 | 2.8″ | HR410857 | Four-wire resistive touch screen | F+G | 68.80*49.60 | 58.60*44.20 | FPC |
| 4 | 3.5″ | HR410269 | Four-wire resistive touch screen | F+G | 82.15*53.40 | 74.10*46.20 | FPC |
| 5 | 3.5″ | HR48544 | Four-wire resistive touch screen | P+F+G | 99.20*75.40 | 72.50*55.00 | FPC |
| 6 | 4.3″ | HR410818 | Four-wire resistive touch screen | F+G | 105.50*67.20 | 97.04*55.86 | FPC |
| 7 | 5.0″ | HR48623 | Four-wire resistive touch screen | F+G | 120.20*74.80 | 110.80*63.80 | FPC |
| 8 | 7.0″ | HR49776 | Four-wire resistive touch screen | P+F+G | 164.90*100.00 | 155.08*86.92 | FPC |
| 9 | 7.0″ | HR49943 | Four-wire resistive touch screen | F+G | 164.20*99.10 | 153.50*85.40 | FPC |
| 10 | 7.0″ | HR410195 | Four-wire resistive touch screen | F+G | 164.50*99.65 | 152.90*84.75 | FPC |
| 11 | 7.0″ | HR510552 | Five-wire resistive touch screen | F+G+LCM | 168.00*109.00 | 151.35*84.35 | FPC |
| 12 | 8.0″ | HR48626 | Four-wire resistive touch screen | F+G | 182.50*140.00 | 162.20*121.80 | FPC |
| 13 | 8.0″ | HR47477 | Four-wire resistive touch screen | F+G | 183.00*141.00 | 162.00*121.50 | FPC |
| 14 | 10.1″ | HR49841 | Four-wire resistive touch screen | F+G | 235.00*142.50 | 222.72*125.28 | FPC |
| 15 | 10.4” | HR49351 | Four-wire resistive touch screen | F+G | 228.20*175.40 | 212.20*159.40 | FPC |
| 16 | 12.1” | HR48622 | Four-wire resistive touch screen | F+G | 261.00*204.50 | 246.50*185.00 | FPC |
| 17 | 12.1” | HR59326 | Five-wire resistive touch screen | F+G | 271.27*205.74 | 246.00*184.50 | FPC |
| 18 | 15″ | HR48629 | Four-wire resistive touch screen | F+G | 324.50*251.00 | 304.10*228.10 | FPC |
| 19 | 15″ | HR59356 | Five-wire resistive touch screen | F+G | 322.00*245.50 | 303.50*227.50 | FPC |
| 20 | 15″ | HR510847 | Five-wire resistive touch screen | F+G | 348.00*273.60 | 302.40*226.90 | FPC |
| 21 | 17″ | HR59325 | Five-wire resistive touch screen | F+G | 356.00*286.50 | 337.60*270.00 | FPC |
| 22 | 17″ | HR510755 | Five-wire resistive touch screen | P+F+G | 382.40*323.40 | 339.92*272.34 | FPC |
| 23 | 21.5″ | HR59231 | Five-wire resistive touch screen | F+G | 495.00*291.60 | 477.64*269.11 | FPC |
