LCD Display Catalog
Combines monochrome/color display and touch into one
LCD Display Catalog
Description
Description
Mono Display Moudle
| Model | Structure | Size | Resolution | Dimensions（mm) | Mode | Form | Viewing Area (mm) | Viewing Angle | Backlight | IC | Port | Type |
| HSG88103-11 | LCD+IC+FPC+BLD | 3.5 | 103 ICONS | 52.0*86.5 | FSTN | Positive, transmissive | 49.0*79.0 | 6 0’clock | White | BU91R61ACH-3BW | IIC | Segment |
| TOUCH7 | LCD+IC+FPC | 2.7 | 41ICONS | 61.0*42.0 | VA | Negative,transmissive | 57.0*36.0 | 12 0’clock | / | UC1650d | serial port | Segment |
| HSG13265-14 | LCD+IC+FPC | 3 | 132*65 | 78.9*48.72 | STN(Y-G) | Positive, transflective | 71.1*39.20 | 12 0’clock | / | ST7565R-G | parallel port/serial port | Dot Matrix |
| HHG88168-05 | LCD+IC+PIN | 2.7 | 168 ICONS | 74*24 | HTN | Positive, transflective | 65.00*21.00 | 6 0’clock | / | BU91R61ACH-3BW | IIC | Segment |
| HSG20880-28 | LCD+IC+PIN | 2.4 | 208*80 | 65*34*2.85 | FSTN | Positive, transflective | 60*25 | 6 0’clock | / | ST75263S | serial port | Dot Matrix |
| HSG20880-29 | LCD+IC+PIN | 3.3 | 208*80 | 85*43*2.8 | FSTN | Positive, transflective | 81*33 | 6 0’clock | / | ST75263S | serial port | Dot Matrix |
| QSG160160-27 | LCD+IC+FPC+BLD | 3.1 | 160*160 | 66.55*72.20 | FSTN | Positive, transflective | 60*60 | 6 0’clock | White | ST75161 | parallel port | Dot Matrix |
| HHB39803 | LCD+PIN | 2.6 | / | 64*38 | HTN | Positive, transflective | 60*30 | 6 0’clock | / | / | / | Segment |
| HHF36258 | LCD+PIN | 3.8 | / | 90*59 | HTN | Positive, Refcective | 85*50 | 6 0’clock | / | / | / | Segment |
| HSF39795 | LCD+PIN | 0.5 | / | 64*36.5 | FSTN | Positive, transflective | 60*30 | 6 0’clock | / | / | / | Segment |
| HSR37735 | LCD+PIN | 3.9 | / | 89*59 | FSTN | Positive, transflective | 85*50 | 6 0’clock | / | / | / | Segment |
| HSR39615 | LCD+PIN | 2.9 | 74.3*28.8 | STN | Positive, transflective | 71.3*22.5 | 6 0’clock | / | / | / | Segment | |
| HTD37330 | LCD+PIN | 2.4 | / | 54*38 | TN | Positive, transflective | 52*32 | 6 0’clock | / | / | / | Segment |
| HTA26082 | LCD+PIN | 3.7 | / | 96.5*38 | 光阀 | Positive, transmissive | 89.5*35 | 10:30’clock | / | / | / | Light Valve |
| HTR37704 | LCD+PIN | 1.5 | / | 17.70*40.70 | Segment | Positive, Refcective | 14.70*33.70 | 6 0’clock | / | / | / | Segment |
CTP Moudle
| Application | Structural Type | Size | Cover Plate Thickness | Number of Supported Touch Points | Dimensions （mm) | Interface |
| POScategory | G+FF | 5.5 | 1.1 | Five points | 149.7*76.05*1.45 | I2C |
| G+FF | 4 | 0.7 | Five points | 115.13*60.38*0.95 | I2C | |
| Security access | G+F | 4.3 | 1.1 | single | 115.6*115.6*1.35 | I2C |
| G+F | 7 | 0.7 | single | 173*111.5*0.95 | I2C | |
| G+FF | 4.3 | 1.1 | Five points | 115.6*115.6*1.43 | I2C | |
| G+G | 7 | 0.7 | Five points | 173*111.5*1.3 | I2C | |
| G+G | 10.1 | 1.8 | Ten points | 254*166*2.55 | I2C | |
| G+FF | 9 | 3.2+0.7 | Ten points | 217.41*138.75*4.45 | I2C | |
| P+G | 7 | 0.25 | Five points | 164.8*99.8*1.55 | I2C | |
| Smart home touch products | G+FF | 9 | 3.2+0.7 | Ten points | 217.41*138.75*4.45 | I2C |
| G+G | 8.6 | 1.1 | Five points | 198.4*128.9*3.65 | USB | |
| G+G | 12.1 | 1.8 | Five points | 265.50*208*3.95 | USB | |
| P+G | 7 | 0.25 | Five points | 164.8*99.8*1.55 | I2C | |
| Medical device touch display products | G+G | 10.1 | 1.1 | Ten points | 239.56*163.56*2.0 | I2C |
| G+G | 13.3 | 0.7 | Ten points | 305,35*178,11*1.45 | I2C | |
| G+G | 15.6 | 2 | Ten points | 368.3*227.77*2.75 | USB | |
| Automotive electronic touch display products | G+FF | 15.6 | 1.6 | Ten points | 373.63*233.34*2.1 | I2C |
| G+G | 7 | 1.1 | Ten points | 187.06*115.07*2.0 | I2C | |
| G+G | 8 | 0.7 | Ten points | 212.8*116.9*1.93 | I2C | |
| Business Education | G+FF | 27 | 3.2 | Ten points | 755.36*542.60*3.7 | USB |
| G+G | 21.5 | 2 | Ten points | 520*312*2.95 | USB | |
| Smart wearable | G+F | 0.92 | 0.7 | single | 26.4*25.81*0.88 | I2C |
| G+F | 1.3 | 2 | single | 44.69*44.69*2.25 | I2C | |
| （round） | ||||||
| G+FF | 1.2 | 1.3 | Five points | 39.7*39.7*1.55 | I2C | |
| （round） | ||||||
| Industrial | G+F | 4 | 0.7 | single | 114.4*61.2*0.95 | I2C |
| G+FF | 10.8 | 0.55 | Five points | 253.8*159.8*1.0 | I2C |
RTP Moudle
| Number | Size | Model | Product Type | Structure | Dimensions（mm） | LCD AA（mm） | Interface |
| 1 | 2.0″ | QR46286 | Four-wire resistive touch screen | F+G | 47.85*42.37 | 39.10*31.90 | FPC |
| 2 | 2.4″ | HR410243 | Four-wire resistive touch screen | F+G | 58.80*42.12 | 49.86*37.72 | FPC |
| 3 | 2.8″ | HR410857 | Four-wire resistive touch screen | F+G | 68.80*49.60 | 58.60*44.20 | FPC |
| 4 | 3.5″ | HR410269 | Four-wire resistive touch screen | F+G | 82.15*53.40 | 74.10*46.20 | FPC |
| 5 | 3.5″ | HR48544 | Four-wire resistive touch screen | P+F+G | 99.20*75.40 | 72.50*55.00 | FPC |
| 6 | 4.3″ | HR410818 | Four-wire resistive touch screen | F+G | 105.50*67.20 | 97.04*55.86 | FPC |
| 7 | 5.0″ | HR48623 | Four-wire resistive touch screen | F+G | 120.20*74.80 | 110.80*63.80 | FPC |
| 8 | 7.0″ | HR49776 | Four-wire resistive touch screen | P+F+G | 164.90*100.00 | 155.08*86.92 | FPC |
| 9 | 7.0″ | HR49943 | Four-wire resistive touch screen | F+G | 164.20*99.10 | 153.50*85.40 | FPC |
| 10 | 7.0″ | HR410195 | Four-wire resistive touch screen | F+G | 164.50*99.65 | 152.90*84.75 | FPC |
| 11 | 7.0″ | HR510552 | Five-wire resistive touch screen | F+G+LCM | 168.00*109.00 | 151.35*84.35 | FPC |
| 12 | 8.0″ | HR48626 | Four-wire resistive touch screen | F+G | 182.50*140.00 | 162.20*121.80 | FPC |
| 13 | 8.0″ | HR47477 | Four-wire resistive touch screen | F+G | 183.00*141.00 | 162.00*121.50 | FPC |
| 14 | 10.1″ | HR49841 | Four-wire resistive touch screen | F+G | 235.00*142.50 | 222.72*125.28 | FPC |
| 15 | 10.4” | HR49351 | Four-wire resistive touch screen | F+G | 228.20*175.40 | 212.20*159.40 | FPC |
| 16 | 12.1” | HR48622 | Four-wire resistive touch screen | F+G | 261.00*204.50 | 246.50*185.00 | FPC |
| 17 | 12.1” | HR59326 | Five-wire resistive touch screen | F+G | 271.27*205.74 | 246.00*184.50 | FPC |
| 18 | 15″ | HR48629 | Four-wire resistive touch screen | F+G | 324.50*251.00 | 304.10*228.10 | FPC |
| 19 | 15″ | HR59356 | Five-wire resistive touch screen | F+G | 322.00*245.50 | 303.50*227.50 | FPC |
| 20 | 15″ | HR510847 | Five-wire resistive touch screen | F+G | 348.00*273.60 | 302.40*226.90 | FPC |
| 21 | 17″ | HR59325 | Five-wire resistive touch screen | F+G | 356.00*286.50 | 337.60*270.00 | FPC |
| 22 | 17″ | HR510755 | Five-wire resistive touch screen | P+F+G | 382.40*323.40 | 339.92*272.34 | FPC |
| 23 | 21.5″ | HR59231 | Five-wire resistive touch screen | F+G | 495.00*291.60 | 477.64*269.11 | FPC |
| Application | Size | Resolution | Touch | LCD type | LCD AA | Interface | Temperature | （ZIF/BTB） | Brightness |
| Retail | 10.1″ | 800X1280 | Incell | IPS | 135.36*216.58 | MIPI | OT: -10°C~50°C ST: -20°C~60°C | 40PIN ZIF | 250ccd/m² MIN,300cd/m² TYP |
| Two-wheeled vehicle | 3.5″ | 320×480 | Add-on CTP | IPS | 49.66x 74.14 | MCU 24 Pin | OT:-20°C~70°C ST:-30°C~80°C | GND | / |
| 4.3″ | 480×272 | Add-on CTP | IPS | 95.04*53.86 | RGB 24bit | OT:-30°C~85°C ST:-30°C~85°C | ZIF | 1000cd/m² (TYP) | |
| 4.95″ | 480×854 | Add-on CTP | IPS | / | RGB | OT:-20°C~70°C ST:-30°C~80°C | ZIF | 800cd/m² (TYP) | |
| 5″ | 800×480 | Add-on CTP | IPS | 108*64.8 | RGB | OT:-20°C~70°C ST:-30°C~80°C | ZIF | 1000cd/m² (TYP) | |
| 5″ | 800×480 | Add-on CTP | IPS | 108*64.8 | RGBW | OT:-30°C~80°C ST:-30°C~85°C | ZIF | 1000cd/m² (TYP) | |
| 5″ | 1024X600 | Add-on CTP | IPS | 107.8*64.8 | RGB | OT:-30°C~85°C ST:-30°C~85°C | ZIF | 1000cd/m² (TYP) | |
| 6.2″ | 1028X600 | Add-on CTP | IPS | 137.47*77.23 | MIPI | OT:-30°C~85°C ST:-30°C~85°C | ZIF | 1000cd/m² (TYP) | |
| 7″ | 1024X600 | Add-on CTP | IPS | 154.21*85.92 | MIPI | OT:-30°C~85°C ST:-30°C~90°C | ZIF | 1000cd/m² (TYP) | |
| Consumer electronics | 3.95″ | 720X720 | Incell | IPS | 70.53× 71.28 | MIPI 4-lane DSI | OT: -20°C~60°C ST: -30°C~70°C | ZIF | 350cd/m² (MIN),380cd/m² (TYP) |
| Security access | 2.4″ | 240×320 | Add-on CTP | TN | 36.72*48.96 | 16位MCU | OT: -20°C~60°C ST: -30°C~80°C | 36PIN ZIF | 300cd/m² (MIN), 350cd/m² (TYP) |
| 2.8“ | 240×320 | Add-on CTP | TN | 43.2*57.6 | 16位MCU | OT: -20°C~70°C ST: -30°C~80°C | 36PIN ZIF | 240cd/m²（min） | |
| 4.3″ | 480X272 | Add-on CTP | TN | 95.04*53.856 | RGB | OT: -20°C ~ 70°C ST:-30°C ~ 80°C | 40PIN ZIF | 300-350cd/m² | |
| 7″ | 800×480 | Add-on CTP | TN | 153.84*85.63 | RGB | OT: -20°C~70°C ST: -30°C~80°C | 50PIN ZIF | 800cd/m² (MIN), 900cd/m² (TYP) | |
| 7″ | 1024×600 | Add-on CTP | TN | 154.21*85.92 | 30PIN MIPI | OT: -20°C ~ 60°C ST:-30°C ~ 70°C | 30PIN ZIF | 250ccd/m² MIN, 300cd/m² TYP | |
| 7“ | 1024×600 | Incell | IPS | 154.2144×85.92 | MIPI | OT: -20°C ~ 60°C ST:-30°C ~ 70°C | 40PIN ZIF | 400cd/m² 450cd/m² Typ. | |
| 7“ | 1024×600 | Incell | IPS | 153.6(H)x90(V) | MIPI | OT: -10°C~60°C ST: 0°C~50°C | 40PIN ZIF | 210cd/m² MIN, 250cd/m² TYP | |
| 8” HD | 800X1280 | Incell | IPS | 107.64×172..22 | MIPI | OT: -20°C~70°C ST: -30°C~80°C | 40PIN ZIF | 250cd/m² -300cd/m² Typ | |
| 10.1″ | 1024×600 | Add-on CTP | IPS | 222.72*125.28 | RGB | OT: -20°C~70°C ST: -10°C~60°C | 50PIN BTB | 300cd/m² Typ | |
| 10.1″HD | 800X1280 | Add-on CTP | IPS | 135.36*216.58 | MIPI | OT: -20°C ~ 60°C ST:-30°C ~ 70°C | BTB 40PIN | 300cd/m² Typ | |
| POS | 3.97″ | 480*800 | Add-on CTP | IPS | 51.84*86.4 | MIPI | OT: -20°C~70°C ST: -30°C~80°C | 30PIN BTB | 250cd/m2(TYP) |
| 5″ | 720*1280 | Add-on CTP | IPS | 62.1*110.4 | MIPI | OT: -20°C ~ 70°C ST:-30°C ~ 80°C | 30PIN BTB | 255cd/m² MIN, 295cd/m² TYP | |
| 5″ | 480×272 | Incell | IPS | 62.10*110.40 | MIPI | OT: -20°C ~ 70°C ST:-30°C ~ 80°C | 33PIN BTB | 240cd/m²（typ） | |
| 5.5″ | 720×1280 | Add-on CTP | IPS | 68.04*120.96 | MIPI | OT: -20°C ~ 70°C ST:-30°C ~ 80°C | 31PIN ZIF | 240cd/m²（min） | |
| 5.5″ | 720×1440 | Incell | IPS | 67.64*120.56 | MIPI | OT: -20°C ~ 70°C ST:-30°C ~ 80°C | 39PIN BTB | 300cd/㎡ min, 360cd/㎡ typ | |
| 6.38″ | 720×1158 | Incell | IPS | 67.93×152.09 | MIPI | / | / | / | |
| 6.56″ | 720*1612 | Incell | IPS | 67.93*152.09 | MIPI | OT:-10°C ~ 50°C, ST:-30°C ~ 60°C; | 40PIN BTB | 300cd-㎡ min | |
| 6.745″ | 720*1612 | Incell | IPS | 67.93*152.09 | MIPI | OT: -20°C ~ 70°C ST:-30°C ~ 80°C | 40PIN BTB | 470cd/㎡ min, 520cd/㎡ typ | |
| 10.1″ | 800×1280 | Add-on CTP | IPS | 135.36*216.58 | 40PIN MIP | OT: -10°C ~ 50°C ST:-20°C ~ 60°C, | 40PIN BTB | 250cd/m²（typ） | |
| 15.6″ | 1920*1080 | Add-on CTP | IPS | 344.16*193.59 | 30PIN eDP | OT: -10°C ~ 50°C ST:-20°C ~ 60°C, | 30PIN BTB | 350cd/m²（typ） | |
| Smart home | 2.25″ | 256×96 | Add-on CTP | MONO TFT | 52.99*21.696 | SPI | OT: -20°C~70°C ST: -30°C~80°C | 15PIN ZIF | 350cd/m² |
| 2.4“ | 240×320 | Add-on CTP | TN | 36.72*48.96 | SPI | OT: -20°C~70°C ST: -30°C~80°C | 20PIN ZIF | 160cd-m2(MIN),180cd-m2(TYP) | |
| 2.8″ | 240×320 | Add-on CTP | IPS | 43.2*57.6 | MIPI | OT: -20°C~70°C ST: -30°C~80°C | 40PIN ZIF | 500cd/m² MIN，550cd/m² TYP | |
| 3.95″ | 480×800 | Add-on CTP | IPS | 71.856 (H) × 70.176(V) | MIPI | ST:-20°C ~ 70°C OT: -10°C ~ 60°C | 20PIN ZIF | 300cd/m² MIN，350cd/m² TYP | |
| 3.95″ | 720×720 | Add-on CTP | IPS | 71.93×71.91 | MIPI | ST:-20°C ~ 70°C OT: -10°C ~ 60°C | 20PIN ZIF | 300cd/m² MIN，350cd/m² TYP | |
| 4.3″ | 480×800 | Add-on CTP | IPS | 56.16*93.6 | MIPI | OT: -20°C ~ 70°C ST:-30°C ~ 80°C | 40PIN ZIF | 450cd/m² MIN,500cd/m² TYP | |
| 5“ | 480×854 | Add-on CTP | IPS | 61.63*109.65 | RGB | OT: -20 ℃ – 70 ℃ ST: -30 ℃ – 80 ℃ | 40PIN ZIF | 360-400cd/m² | |
| 8″ | 800×1280 | Add-on CTP | IPS | 107.64*172.22 | MIPI | ST:-20°C ~ 60°C OT: -10°C ~ 50°C | BTB 31PIN | 250cd/m²MIN；300cd/m²TYP | |
| 9″ | 1024×600 | Add-on CTP | IPS | 196.61*114.15 | MIPI | OT: -20°C~70°C ST: -30°C~80°C | 40PIN ZIF | 450cd/m² MIN,500cd/m² TYP | |
| 10.1″ | 800×1280 | Add-on CTP | IPS | 135.36*216.58 | MIPI | OT: -20°C ~ 70°C ST:-30°C ~ 80°C | BTB 40PIN | 300cd/m²(MIN),350cd/m²(TYP) | |
| HMI | 3.5″ | 320×240 | Add-on CTP | TN | / | / | OT: -20°C~70°C ST: -30°C~80°C | / | / |
| 4.3″ | 480X272 | Add-on CTP | TN | 95.04*53.856 | RGB | OT: -20°C TO 70°C ST:-30°C TO 80°C | 40PIN ZIF | 300-350cd/m² | |
| 4.3″ | 800×480 | Add-on CTP | IPS | 95.04×53.86 | RGB | OT: -20°C TO 70°C ST:-30°C TO 80°C | 40PIN ZIF | 350cd-m² Min | |
| 5.0″ | 800×480 | Add-on CTP | IPS | / | / | OT: -20°C~70°C ST: -30°C~80°C | / | / | |
| 7″ | 800×480 | Add-on CTP | TN | / | / | OT: -20°C~70°C ST: -30°C~80°C | / | / | |
| 7″ | 800×480 | Add-on CTP | TN | 153.84*85.63 | RGB | OT: -20°C~70°C ST: -30°C~80°C | 50PIN ZIF | 800cd/m² (MIN), 900cd/m² (TYP) | |
| 7″ | 1024×600 | Add-on CTP | IPS | 154.21*85.92 | 30PIN MIPI | OT: -20°C ~ 60°C ST:-30°C ~70°C | 30PIN ZIF | 250ccd/m² MIN, 300cd/m² TYP | |
| 10.1″ | 1024×600 | Add-on CTP | TN | 222.72×125.28 | 50PIN RGB | OT: -20°C ~ 55°C ST:-30°C ~70°C | ZIF | 200cd/m² MIN, 250cd/m² TYP | |
| 15.6” | 1920×1080 | Add-on CTP | IPS | / | / | OT: -20°C~70°C ST: -30°C~80°C | / | / |
