Diversified display structures, supporting customized development according to customer requirements
High-precision display, low-power consumption design, and strong compatibility
High reliability, capable of meeting the high-temperature and high-humidity requirement (85℃/85%RH for 1000 hours), with a maximum product design lifespan of 16 years
Ultra-wide operating temperature range, wide viewing angle, and stable quality
| Product Type | structure | Overall Dimensions | Mode | Form | Viewing Area | Viewing Angle | Backlight | IC | Port | Type | |
| LCM | LCM | LCD+IC+FPC | 29.86*18.72 | FSTN | Positive, transflective | 27.86*14.42 | 6 0’clock | / | ST7567A | IIC | dot matrix |
| LCM | LCD+IC+FPC | 38.6*20.0 | STN(Y-G) | Positive,Reflective | 34.6*15 | 6 0’clock | / | ST7567S | serial port | dot matrix | |
| LCM | LCD+IC+FPC+BLD | 79.2*42 | FSTN | Positive, transflective | 63.46*23 | 6 0’clock | White | ST7565R | parallel port | dot matrix+ICON | |
| LCM | LCD+IC+FPC | 53.4*25.5 | FSTN | Positive,Reflective | 50.4*17.20 | 6 0’clock | / | IST3080CA1 | serial port | dot matrix | |
| LCM | LCD+IC+FPC+BLD | 93*38.8 | VA | Negative,transmissive | 88*29.5 | 12 0’clock | White | BU91R61ACH-3BW | IIC | Segment | |
| LCM | LCD+IC+FPC+BLD | 74.3*56.3 | HTN | Positive,transmissive | 68.8*45.8 | 12 1’clock | White | CN91C4S48 | IIC | Segment | |
| LCM | LCD+IC+FPC+BLD | 66.55*72.20 | FSTN | Positive, transflective | 60*60 | 6 0’clock | White | ST75161 | parallel port | dot matrix | |
| LCM | LCD+IC+PIN | 65*34*2.85 | FSTN | Positive, transflective | 60*25 | 6 0’clock | / | ST75263S | serial port | dot matrix | |
| LCM | LCD+IC+PIN | 85*43*2.8 | FSTN | Positive, transflective | 81*33 | 6 0’clock | / | ST75263S | serial port | dot matrix | |
| LCM | LCD+IC+FPC+BLD | 98.9*54.4 | ASTN | Negative,transmissive | 92.98*41.32 | 6 0’clock | White | ST7599 | serial port | dot matrix | |
| LCM | LCD+BLD | 46.6*56.4 | FSTN | Positive, transmissive | 44.2*46.7 | 6 0’clock | Yellow | / | / | Segment | |
| LCM | LCD+IC+FPC+BLD | 52.0*86.5 | FSTN | Positive, transmissive | 49.0*79.0 | 6 0’clock | White | BU91R61ACH-3BW | IIC | Segment | |
| LCD | LCD | LCD+PIN | 64*38 | HTN | Positive, transflective | 60*30 | 6 0’clock | / | / | / | Segment |
| LCD | LCD+PIN | 90*59 | HTN | Positive, Refcective | 85*50 | 6 0’clock | / | / | / | Segment | |
| LCD | LCD+PIN | 64*36.5 | FSTN | Positive, transflective | 60*30 | 6 0’clock | / | / | / | Segment | |
| LCD | LCD+PIN | 89*59 | FSTN | Positive, transflective | 85*50 | 6 0’clock | / | / | / | Segment | |
| LCD | LCD+PIN | 40*25 | STN | Positive, Refcective | 37*17 | 6 0’clock | / | / | / | Segment | |
| LCD | LCD+FPC | 58.09*33.7 | 3D | Positive, transmissive | 53.69*31.33 | 10:30’clock | / | / | / | 3D | |
| LCD | LCD+PIN | 96.5*38 | Optical Shutter | Positive, transmissive | 89.5*35 | 10:30’clock | / | / | / | Optical Shutter | |
| LCD | LCD | 40*45 | TN | Positive, Refcective | 33*42 | 6 0’clock | / | / | / | Segment | |
| LCD | LCD+PIN | 75*19 | VA | negative, transmissive | 72*14 | 12’clock | / | / | / | Segment | |
| LCD | LCD+PIN | 54*38 | TN | Positive, transflective | 52*32 | 6 0’clock | / | / | / | Segment | |
| LCD | LCD+PIN | 68*27 | TN | Positive, Refcective | 64*19 | 6 0’clock | / | / | / | Segment |
