TFT LCD
Combines monochrome/color display and touch into one
TFT LCD
Strong supply chain integration capabilities
Comprehensive product line: Offering an integrated portfolio covering TN, TFT (On-cell/In-cell), OLED, LCM, and TLCM
Rigorous quality control: Equipped with an IT-based application management platform and adhering to international quality system standards
Description
Description
| Apply | Size | Resolution | LCD type | HLT model | Structure | IC | LCD AA | Dimensions/W*H*D | Interface | Temperature | （ZIF/BTB） | (with-without TP) |
| Retail | 10.1″ | 800X1280 | IPS | HQBDR101H306 | TFT | JD9365DA-H3 | 135.36*216.58 | 142.98*228.58*2.67 | MIPI | OPERATING TEMP: -10°C~50°C STORAGE TEMP: -20°C~60°C | 40PIN ZIF | 250ccd/m² MIN,300cd/m² TYP |
| Security access control touch display products | 2.4″ | 240×320 | TN | HIB024A073 | TFT | ST7789V | 36.72*48.96 | 42.72*60.26*2.24 | 16位MCU | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 36PIN ZIF | 300cd/m² (MIN),350cd/m² (TYP) |
| 2.8“ | 240×320 | TN | HIB028A050 | TFT | ST7789V | 43.2*57.6 | 50*69.2*2.35 | 16位MCU | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 36PIN ZIF | 240cd/m²（min） | |
| 4.3″ | 480X272 | TN | HIB043B106 | TFT | ST7283 | 95.04*53.856 | 105.5*67.2*3.00 | RGB | OPERATING TEMP: -20°C ~ 70°C STORAGE TEMP:-30°C ~ 80°C | 40PIN ZIF | 300-350cd/m² | |
| 7″ | 800×480 | TN | HIK070W409 | TFT+CTP | HX8264+HX8664 | 153.84*85.63 | 164.9*100*5.65 | RGB | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 50PIN ZIF | 800cd/m² (MIN),900cd/m² (TYP) | |
| 7″ | 1024×600 | TN | HIK070H243 | TFT+CTP | EK79007+ EK73217 | 154.21*85.92 | 164.9*100*2.8 | 30PIN MIPI | OPERATING TEMP: -20°C ~ 60°C STORAGE TEMP:-30°C ~ 70°C | 30PIN ZIF | 250ccd/m² MIN,300cd/m² TYP | |
| 7“ | 1024×600 | Incell | HIK070H416 | TFT | JD9165T | 154.2144(H)x85.92(V) | 173(H)x111.5(V)x4.39(T) | MIPI | OPERATING TEMP: -10°C~60°C STORAGE TEMP: 0°C~50°C | 40PIN ZIF | 210cd/m² MIN,250cd/m² TYP | |
| 7“ | 1024×600 | Incell | HIF070H417 | TFT | ST7232 | 153.6(H)x90(V) | 173(H)x111.5(V)x4.07(T) | MIPI | OPERATING TEMP: -10°C~60°C STORAGE TEMP: 0°C~50°C | 40PIN ZIF | 210cd/m² MIN,250cd/m² TYP | |
| 10.1″ | 800X1280 | IPS | HIB101H277 | TFT | JD9365DA | 135.36*216.58 | 142.88*228.54*2.66 | MIPI | OPERATING TEMP: -20°C ~ 60°C STORAGE TEMP:-30°C ~ 70°C | BTB 40PIN | with TP:350cd/m² MIN, 400cd/m² TYP | |
| Financial touch products | 2.4″ | 240×320 | TN | HIB024A380 | TFT | ST7789V3A | 36.72*48.96 | 60.46*42.96*1.85 | MCU | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 26PIN BTB | 360cd/m²(MIN), 420cd/m²(TYP) |
| 2.8″ | 240×320 | TN | HJR028A178 | TFT+CTP | ST7789V2 | 43.2*57.6 | 50*69.2*.66 | 8bit | OPERATING TEMP: -20°C ~ 70°C STORAGE TEMP:-30°C ~ 80°C | 40PIN ZIF | with TP: 440cd/m² MIN,500cd/m² TYP | |
| 4.3″ | 480×272 | TN | HIB043B063 | TFT | ST7282 | 95.04*53.856 | 105.5*67.2*4.05 | RGB | OPERATING TEMP: -20°C ~ 70°C STORAGE TEMP:-30°C ~ 80°C | 40PIN ZIF | 400cd/m² TYP | |
| 5″ | 720×1280 | IPS | HIB050H1088 | TFT | HX8394 | 62.1*110.4 | 65*119.75*1.75 | MIPI | OPERATING TEMP: -20°C ~ 70°C STORAGE TEMP:-30°C ~ 80°C | 30PIN BTB | 255cd/m² MIN,295cd/m² TYP | |
| 5.5″ | 720×1280 | IPS | HOB055H992 | TFT | HX8394 | 68.04*120.96 | 70.04*131.61*1.8 | 31PIN MIPI | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 31PIN ZIF | 240cd/m²（min） | |
| 10.1″ | 800×1280 | IPS | HOT101H185 | TFT+CTP | JD9365DA | 135.36*216.58 | 142.96*228.80 | 40PIN MIPI | OPERATING TEMP: -10°C ~ 50°C STORAGE TEMP:-20°C ~ 60°C, | 40PIN BTB | 370nits（TYP） | |
| Smart wearable touch display products | 1.3″ | 240×240 | IPS （Square screen） | HSB013A048 | TFT+CTP | ST7789H2 | 23.4*23.4 | 26.0*29.15*1.5 | QSPI | OPERATING TEMP: -20 ℃ – 70 ℃ STORAGE TEMP: -30 ℃ – 80 ℃ | 24PIN BTB | 480cd/m² Min 530cd/m² Typ |
| Smart home touch products | 2.25″ | 256×96 | MONO TFT | HJB023A009 | TFT | ST7735SV | 52.99*21.696 | 57.09*30.10*2.8 | SPI | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 15PIN ZIF | 350cd/m² |
| 2.4“ | 240×320 | TN | HOR024A329 | TFT+CTP | GC9306 | 36.72*48.96 | 42.72*60.26*3.30 | SPI | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 20PIN ZIF | 160cd-m2(MIN),180cd-m2(TYP) | |
| 2.8″ | 240×320 | IPS | HJB028A196 | TFT | ST7785MA | 43.2*57.6 | 59.80*77.56*4.05 | MIPI | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 40PIN ZIF | 500cd/m² MIN，550cd/m² TYP | |
| 3.95″ | 480×800 | IPS | HJTAS040B244 | TFT | ST7701PN | 71.856 (H) × 70.176(V) | 74.66(H)×76.54(W)×2.1(T) | RGB | STORAGE TEMP:-20°C ~ 70°C OPERATING TEMP: -10°C ~ 60°C | 20PIN ZIF | 300cd/m² MIN，350cd/m² TYP | |
| 4.3″ | 480×800 | IPS | HJT043W109 | TFT+CTP | ST7701SN | 56.16*93.6 | 98.1*110.98*7.34 | MIPI | OPERATING TEMP: -20°C ~ 70°C STORAGE TEMP:-30°C ~ 80°C | 40PIN ZIF | 450cd/m² MIN,500cd/m² TYP | |
| 5“ | 480×854 | IPS | HIB050W1173 | TFT | ST7701S | 61.63*109.65 | 66.40*120.0*2.2 | RGB | OPERATING TEMP: -20 ℃ – 70 ℃ STORAGE TEMP: -30 ℃ – 80 ℃ | 40PIN ZIF | 360-400cd/m² | |
| 8″ | 800×1280 | IPS | HJB080H119 | TFT+CTP | JD9365DA | 107.64*172.22 | 114.6*184.1*2.6 | MIPI | STORAGE TEMP:-20°C ~ 60°C OPERATING TEMP: -10°C ~ 50°C | BTB 31PIN | 250cd/m²MIN；300cd/m²TYP | |
| 9″ | 1024×600 | IPS | HJT090H021 | TFT+CTP | JD9165BA | 196.61*114.15 | 219.6*148.65*8.16 | MIPI | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 40PIN ZIF | 450cd/m² MIN,500cd/m² TYP | |
| 10.1″ | 800×1280 | IPS | HJB101H267 | TFT | JD9365DA | 135.36*216.58 | 142.88*228.54*2.66 | MIPI | OPERATING TEMP: -20°C ~ 70°C STORAGE TEMP:-30°C ~ 80°C | BTB 40PIN | 300cd/m²(MIN),350cd/m²(TYP) | |
| Medical device touch display products | 10.95″ | 1200×2000 | IPS | HIF110F006 | INCELL | FT8205 | 143.10*238.5 | 148.30*247.00*1.70 | MIPI+SPI | OPERATING TEMP: -10~50℃ STORAGE TEMP:-20~60℃ | BTB 51PIN | 320cd/m²（MIN） |
| 2.4“ | 240×320 | TN | HIB024A380 | TFT | ST7789V3A | 36.72*48.96 | 60.46*42.96*1.85 | MCU | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 26PIN BTB | 360cd-m2(MIN), 420cd-m2(TYP) | |
| 2.8″ | 240×320 | TN | HIB028A198 | TFT | ST7789T3 | 43.2*57.6 | 50*69.2*2.3 | 18BIT | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 40PIN ZIF | LCM Luminance： 210cd/m² min;250cd/m² typ | |
| 4.3″ | 480X272 | TN | HIB043B100 | TFT | F043A10 | 95.04*53.856 | 105.5*67.2*2.94 | RGB | OPERATING TEMP: -20°C ~ 70°C STORAGE TEMP:-30°C ~ 80°C | 40PIN ZIF | 300cd/m²Min 350cd/m² Typ | |
| 10.1″ | 800×1280 | IPS | HIB101H268 | TFT | JD9365DA | 135.36*216.53 | 142.88*228.54*2.66 | MIPI | OPERATING TEMP: 0°C ~ 45°C STORAGE TEMP:-20°C ~ 55°C | 30PIN ZIF | 300 cd/m² MIN, 350 cd/m² TYP | |
| HMI | 7“ | 1024×600 | TN | HIBDR070H430 | TFT | EK79007 EK73217 | 154.21(H)x85.92(V) | 164.8(H)x99.9(V)x2.8(T) | MIPI | OPERATING TEMP: -10°C~50°C STORAGE TEMP: -20°C~60°C | 30PIN ZIF | 200 cd/m² MIN, 250 cd/m² TYP |
| 7“ | 800×480 | TN | HIBDR070W431 | TFT | EK73002AB2 | 154.08(H)x85.92(V) | 164.8(H)x100.0(V)x5.7(T) | RGB | OPERATING TEMP: -10°C~50°C STORAGE TEMP: -20°C~60°C | 30PIN ZIF | 200 cd/m² MIN, 250 cd/m² TYP | |
| Automotive electronic touch display products | 4.3″ | 480×272 | IPS | HABNR043B118 | TFT | ST7282 | 95.04(H)x53.856(V) | 105.4(H)x67.1(V)x2.9(T) | RGB | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 40PIN ZIF | 800cd/m2 |
| 4.3″ | 480×272 | IPS | HIBBR043B119 | TFT | ST7262 | 95.04(H)x53.856(V) | 105.4(H)x67.1(V)x2.9(T) | RGB | OPERATING TEMP: -10°C~60°C STORAGE TEMP: -20°C~70°C | 40PIN ZIF | 200 cd/m² MIN, 250 cd/m² TYP | |
| 4.3″ | 480×272 | IPS | HAB043B085 | TFT | ST7262 | 95.04*53.856 | 105.5*67.2*2.94 | 40PIN RGB | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 40PIN ZIF | 280cd/m² | |
| 5″ | 800×480 | IPS | HIBNS050W324 | TFT | ST72568 | 108.0(H)x64.8(V) | 120.7(H)x75.8(V)x2.8(T) | RGB | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 40PIN ZIF | 800cd/m² MIN,850cd/m² TYP | |
| 5″ | 800×480 | IPS | HIBNS050W1192 | TFT | ST72568 | 108.0(H)x64.8(V) | 120.7(H)x75.8(V)x2.8(T) | RGB | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 40PIN ZIF | 550cd/m² MIN,600cd/m² TYP | |
| 5″ | 800×480 | IPS | HAB050W1187 | TFT | ST7262 | 108.0(H)x64.8(V) | 120.7(H)x75.8(V)x2.8(T) | RGB | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 40PIN ZIF | 800cd/m² MIN,1000cd/m² TYP | |
| 5″ | 800×480 | IPS | HAB050W1143 | TFT | ST7262 | 62.10*110.4 | 121.00*78.90*6.70 | 50PIN RGB | OPERATING TEMP: -30°C~85°C STORAGE TEMP: -30°C~80°C | 50PIN ZIF | 1000cd/m² | |
| 7“ | 800×480 | TN | HAB070W392 | TFT | HX8678 HX8249 | 152.40*91.44 | 166.50*105.70*7.30 | LVDS | OPERATING TEMP: -30°C ~ 85°C STORAGE TEMP:-40°C ~ 90°C | 40PIN ZIF | 800cd/m² MIN,1000cd/m² TYP | |
| 8.8″ | 1280×480 | IPS | HAB088H008 | TFT | FL5894AA (Source) ST5043AA(Gate) | 209.28×78.48 | 229.6*97.3*8.7 | LVDS | OPERATING TEMP: -30°C ~ 85°C STORAGE TEMP:-40°C ~ 90°C | 50PIN ZIF | 400cd/m² TYP | |
| 10.25″ | 1920×720 | IPS | HAB101F008 | TFT | HX82102 | 243.648*91.368 | 250.65 × 105.07*8.5 | LVDS | OPERATING TEMP: -30°C ~ 85°C STORAGE TEMP:-40°C ~ 90°C | 50PIN ZIF | 800cd/m² TYP | |
| 12.3″ | 1920×720 | IPS | HIB123F007 | TFT | HX82102*1 HX8692A*2 | 292.032*109.512 | 302.1*125.5*6.35 | LVDS | OPERATING TEMP: -30°C ~ 85°C STORAGE TEMP:-40°C ~ 90°C | 50PIN ZIF | 800cd/m² MIN,1000cd/m² TYP | |
| 15.6″ | 1920×1080 | IPS | HAB156F008 | TFT | HX82102*1 HX8692A*2 | 344.16*193.59 | 363.8×215.98×9.6 | LVDS | OPERATING TEMP: -30°C ~ 85°C STORAGE TEMP:-40°C ~ 90°C | 50PIN ZIF | 800cd/m² MIN,1000cd/m² TYP |
