AMOLED Display Module
Combines monochrome/color display and touch into one
AMOLED Display Module
强大的供应链整合能力
；完善的产品线：提供涵盖TN、TFT（On-cell/In-cell）、OLED、LCM和TLCM的集成产品线；
严格的质量控制：配备基于信息化的应用管理平台，并采用国际质量体系标准。
Description
Description
| 应用 | 尺寸 | 分辨率 | 类型 | 型号 | 结构 | IC | LCD AA（mm) | 外形尺寸/长*宽*厚(mm) | 接口 | 温度 | 连接方式 | 亮度 |
| 智能穿戴 | 1.32″ | 466×466 | ONCELL (OLED Round screen) | HSM013B138 | AMOLED | ICNA3311 | ∅33.5 | 36.35*36.35*0.74 | MIPI | OPERATING TEMP: -20 ℃ – 70 ℃ STORAGE TEMP: -30 ℃ – 80 ℃ | 36PIN BTB | 550cd/m² Min 600cd/m² Typ |
| 1.43” | 466×466 | ONCELL (OLED Round screen) | HSM014B070 | Oncell+CG | ICNA3310(COF) | Φ36.35 | 39.35（L）x 39.55(W) | QSPI | OPERATING TEMP: -20 ℃ -55 ℃ STORAGE TEMP: -30 ℃ – 70 ℃ | 24PIN BTB | 500cd/m² Min 550cd/m² Typ | |
| 1.43″ | 466×466 | ONCELL (OLED Round screen) | HSM014B068 | AMOLED | ICNA3311 | ∅36.35 | 39.55*39.35*0.78 | QSPI | OPERATING TEMP: -20 ℃ – 70 ℃ STORAGE TEMP: -30 ℃ – 80 ℃ | 24PIN BTB | 450cd/m² Min 500cd/m² Typ | |
| 1.6″ | 320×360 | ONCELL (OLED Square screen) | HSM016B037 | AMOLED +CG | CO5300AF | 27.02*30.40 | 35.34*43.30*2.05 | MIPI+SPI | OPERATING TEMP: -20°C TO 60°C STORAGE TEMP: :-30°C TO 65°C | BTB 34PIN | 400cd/m² | |
| 1.72″ | 356×400 | ONCELL (OLED Square screen) | HQF017B022 | Incell | SPD2012 | 29.10*32.70 | 31.50*37.22*1.56 | MIPI | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 30PIN BTB | 300cd/m² Min 350cd/m² Typ | |
| 1.78″ | 368×448 | ONCELL (OLED Square screen) | HQM018B120 | AMOLED | ICNA3311 | 28.70*34.94 | 30.60*37.99*0.75 | MIPI | OPERATING TEMP: -20°C~70°C STORAGE TEMP: -30°C~80°C | 30PIN BTB | 500cd/m² | |
| 1.85″ | 390×450 | ONCELL (OLED Square screen) | HSM019B016 | Oncell+CG | CO5300AF | 30.75*35.48 | 32.39*37.93*2.3 | QSPI+MIPI | OPERATING TEMP: -20℃～70℃ STORAGE TEMP：-30℃～80℃ | BTB 30PIN | 500±50cd/㎡ typ | |
| 1.952″ | 410×502 | ONCELL (OLED Square screen) | HSM020B048 | AMOLED | ICNA3310 | 31.37*38.4 | 33.07*41.05*0.82 | QSPI | OPERATING TEMP: -20 ℃ – 70 ℃ STORAGE TEMP: -30 ℃ – 80 ℃ | 36PIN BTB | 500cd/m² Min 550cd/m² Typ |
